Camarb

Camarb N21-AIO

€0.00
Tax included

Post-bed sewing machine with servo-drive integrated in the sewing head, single needle, rotary feed dog, synchronized needle and presser foot.

Thread trimmer, electric backtracking and electric presser foot lift.

Quantity

Add to favorites Add to compare

APPLICATION AREA

The Camarb N21-ALL-IN-ONE is used for most of sewing works in men/women shoes and leather goods production.

The continuous work of synchronized feed dog and presser foot feeding, make the material scrolling considerably easier.

The thread trimmer, the backtracking and the presser foot lifter make the working progress more efficient.

PRODUCT ADVANTAGES

  • The new servo drive integrated in the sewing head can guarantee a better workstation’s ergonomics
  • 60% energy saving
  • Higher stability during work-cycle steps
  • Less vibrations during the sewing process
  • Improved backtracking quality on first and last stitches with costant stitch lenght during all sewing time
  • Backtracking can be activated manually through the hand lever
  • New thread trimmer, easy to adjust, with short threads cutting system
  • Easy replacement for wearing parts
  • Excellent quality-price ratio for the sewing machine and the spare parts

TECHNICAL DATA

  • Max sewing speed: 2.800 r.p.m. (mod. A-B)
  • Max sewing speed: 2.400 r.p.m. (mod. C)
  • Max stitch lenght: 4,0 mm
  • Kind of stitch: 301
  • Lifting amount of presser foot: 7 mm
  • Needle system: 134-LR
  • Voltage: 230 V - 50/60Hz
  • Dimensions: 105x55x127 cm
  • Weight: 100 kg

Product Details

Camarb N21-AIO

Data sheet

Functions
1 Needle Sewing
Max sewing speed
2.400 r.p.m. (mod. C)
2.800 r.p.m. (mod. A-B)
Max stitch lenght
4,0 mm
Kind of stitch
301
Lifting amount of presser foot
7 mm
Needle system
134-LR
Voltage
230 V - 50/60Hz
Dimensions
105x55x127 cm
Weight
100 kg

Download

Scheda Tecnica N21-AIO

Scheda Tecnica N21-AIO

Download (1.1MB)

Cat. Ricambi CAMARB N21-N22 AIO

Download (2.03MB)

Manuale Uso CAMARB N21-N22 AIO

Download (7.4MB)

Manuale Istr. CAMARB N21-N22 AIO

Download (746.7KB)
